UCC25702D
lmages are for reference only.UCC25702D
IC REG CTRLR MULT TOP 14SOIC
Datasheet14-SOIC (0.154", 3.90mm Width)
63,811 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost, Flyback, Forward Converter Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 14-SOIC
UCC25702D
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive, Isolation Capable |
| Topology | Boost, Flyback, Forward Converter |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 8.8V ~ 15V |
| Frequency - Switching | 100kHz |
| Duty Cycle (Max) | 99% |
| Synchronous Rectifier | No |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Current Limit, Frequency Control, Sequencing, Soft Start |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SOIC |
| Base Product Number | UCC25702 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UCC25702D | UCC25702DTR | UCC25702N | UCC25702N |
| Manufacturer | Unitrode | Texas Instruments | Texas Instruments | Unitrode |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | UCC25702 ADVANCED VOLTAGE MODE P | IC REG CTRLR MULT TOP 14SOIC | IC REG CTRLR MULT TOPOLOGY 14DIP | UCC25702 ADVANCED VOLTAGE MODE P |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Bulk |
