Converter Offline Flyback, Forward Topology 16-SOIC
UCC2580DTR-2
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Flyback, Forward |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 15V |
| Duty Cycle | 66% |
| Frequency - Switching | - |
| Power (Watts) | - |
| Fault Protection | - |
| Control Features | Soft Start |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| Mounting Type | Surface Mount |
| Base Product Number | UCC2580 |
| Voltage - Start Up | 15 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UCC2580DTR-4 | UCC2580DTR-4 | UCC2580D-2 | UCC2580D-2 |
| Manufacturer | Texas Instruments | Unitrode | Unitrode | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SW MULT TOP 16SOIC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Bulk | Bulk | Tube |
