Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
UCC2807D-3/70034
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Unitrode |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Output Type | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Boost, Flyback, Forward Converter |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 4.1V ~ 13.5V |
| Frequency - Switching | 202kHz |
| Duty Cycle (Max) | 78% |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | UCC2807 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UCC2807D-3 | UCC2807D-3G4 | UCC2803J | UCC2806D |
| Manufacturer | Texas Instruments | Texas Instruments | Unitrode | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IC REG CTRLR MULT TOPOLOGY 8SOIC | IC REG CTRLR MULT TOPOLOGY 8SOIC | 1A, 1000KHZ BICMOS, CDIP8 | IC REG CTRLR MULT TOP 16SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tube |
