UCC3813DTR-4
lmages are for reference only.Payment Methods
Delivery Services
Converter Offline Boost, Buck, Flyback, Forward Topology 1MHz 8-SOIC
UCC3813DTR-4
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Unitrode |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Isolation | Either |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Boost, Buck, Flyback, Forward |
| Voltage - Supply (Vcc/Vdd) | 8.3V ~ 12V |
| Duty Cycle | 49% |
| Frequency - Switching | 1MHz |
| Power (Watts) | - |
| Fault Protection | - |
| Control Features | Frequency Control |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Mounting Type | Surface Mount |
| Base Product Number | UCC3813 |
| Voltage - Start Up | 12.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UCC3813DTR-2 | UCC3813DTR-4 | UCC3810DW | UCC3810DW |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Unitrode |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC OFFLINE SWITCH MULT TOP 8SOIC | IC OFFLINE SWITCH MULT TOP 8SOIC | IC OFFLINE SW MULT TOP 16SOIC | IC OFFLINE SW MULT TOP 16SOIC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Bulk |
