UEI15-033-Q12-C
lmages are for reference only.UEI15-033-Q12-C
DC DC CONVERTER 3.3V 14.85W
Datasheet6-DIP Module
71,621 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 3.3V 4.5A 9V - 36V Input
UEI15-033-Q12-C
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Murata Power Solutions Inc. |
| Series | UEI15 (15W) |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 3.3V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 4.5A |
| Power (Watts) | 14.85 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output, Remote On/Off, Standby Output |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 89% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP Module |
| Size / Dimension | 1.10" L x 0.96" W x 0.33" H (27.9mm x 24.4mm x 8.4mm) |
| Supplier Device Package | - |
| Control Features | Enable, Active High |
| Approval Agency | cURus, DEMKO |
| Standard Number | 60950-1 |
| Base Product Number | - |
| Voltage - Isolation | 2.25 kV |
| Product Attribute |  |
 |
 |
 |
| Part Number | UEI15-033-Q12N-C | UEI15-033-Q12NM-C | UEI15-033-Q12P-C | UEI15-033-Q12PM-C |
| Manufacturer | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 3.3V 15W | DC DC CONVERTER 3.3V 15W | DC DC CONVERTER 3.3V 15W | DC DC CONVERTER 3.3V 15W |
| Series | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. | Murata Power Solutions Inc. |
| Packaging | Tray | Tape & Reel (TR) | Tray | Tape & Reel (TR) |
