Product CatalogPart Number
UF3SC120009K4S
Manufacturer
QorvoDescription
SICFET N-CH 1200V 120A TO247-4
Datasheet
DatasheetPackage
TO-247-4
In Stock
86,569 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UF3SC120009K4S
UF3SC120009K4S
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 1200 V 120A (Tc) 789W (Tc) Through Hole TO-247-4
Quick Inquiry
UF3SC120009K4S
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Qorvo |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | SiCFET (Cascode SiCJFET) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 120A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 12V |
| Rds On (Max) @ Id, Vgs | 11mOhm @ 100A, 12V |
| Vgs(th) (Max) @ Id | 6V @ 10mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 8512 pF @ 100 V |
| FET Feature | - |
| Power Dissipation (Max) | 789W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247-4 |
| Package / Case | TO-247-4 |
| Base Product Number | UF3SC120009 |
| Gate Charge (Qg) (Max) @ Vgs | 234 nC @ 15 V |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
|
 |
 |
| Part Number | UF3SC120016K3S | UF3SC120016K4S | UF3SC120040B7S | UF3SC065007K4S |
| Manufacturer | Qorvo | Qorvo | Qorvo | Qorvo |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SICFET N-CH 1200V 107A TO247-3 | SICFET N-CH 1200V 107A TO247-4 | 1200V/40MOHM, SIC, STACKED FAST | MOSFET N-CH 650V 120A TO247-4 |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
