N-Channel 30 V 11A (Ta), 20A (Tc) 3W (Ta), 15W (Tc) Surface Mount 8-SOP
UPA2706GR-E2-AT
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Renesas |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 11A (Ta), 20A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V |
| Rds On (Max) @ Id, Vgs | 15mOhm @ 5.5A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 660 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 3W (Ta), 15W (Tc) |
| Operating Temperature | 150°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOP |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 7.1 nC @ 5 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | UPA2706GR-E1-A | UPA2706GR-E1-AT | UPA2700GR-E1-A | UPA2701GR-E1-AT |
| Manufacturer | Renesas | Renesas | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | UPA2706GR-E1-A - MOS FIELD EFFEC | UPA2706GR-E1-AT - MOS FIELD EFFE | N-CHANNEL POWER MOSFET | MOSFET N-CH 30V 14A 8PSOP |
| Series | - | - | * | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
