Product CatalogPart Number
UPW2A150MPD1TA
Manufacturer
NichiconDescription
CAP ALUM 15UF 20% 100V RADIAL TH
Datasheet
DatasheetPackage
Radial, Can
In Stock
82,048 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UPW2A150MPD1TA
UPW2A150MPD1TA
lmages are for reference only.Payment Methods
Delivery Services
15 µF 100 V Aluminum Electrolytic Capacitors Radial, Can 3000 Hrs @ 105°C
Quick Inquiry
UPW2A150MPD1TA
Specifications
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Nichicon |
| Series | UPW |
| Packaging | Cut Tape (CT)-->Tape & Box (TB) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 15 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 54 mA @ 120 Hz |
| Ripple Current @ High Frequency | 180 mA @ 100 kHz |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Base Product Number | - |
| Impedance | 830 mOhms |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | UPW2A150MPD | UPW2A150MPD1TD | UPW2A010MDD | UPW2A010MDD1TA |
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM 15UF 20% 100V RADIAL TH | CAP ALUM 15UF 20% 100V RADIAL TH | CAP ALUM 1UF 20% 100V RADIAL TH | CAP ALUM 1UF 20% 100V RADIAL TH |
| Series | Nichicon | Nichicon | Nichicon | Nichicon |
| Packaging | Bulk | Cut Tape (CT)-->Tape & Box (TB) | Bulk | Tape & Box (TB) |
