V23092-A1024-A301
lmages are for reference only.V23092-A1024-A301
RELAY GEN PURPOSE SPDT 6A 24V
Datasheet-
44,193 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole
V23092-A1024-A301
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | SNR, SCHRACK |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 6 A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 2400VA |
| Coil Current | 7 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Fully |
| Coil Insulation | - |
| Must Operate Voltage | 16.8 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 12 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Approval Agency | cURus, VDE |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 3.4 kOhms |
| Base Product Number | V23092 |
| Product Attribute |  |
 |
 |
 |
| Part Number | V23092-A1024-A201 | V23092-A1024-A302 | V23092-A1024-A801 | V23092-A1024-X46 (V23092-A |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | |
| Description | RELAY GEN PURPOSE SPDT 6A 24V | RELAY GEN PURPOSE SPST 6A 24V | RELAY GEN PURPOSE SPDT 6A 24V | V23092-A1024-X46 (V23092-A |
| Series | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity |
| Packaging | Tube | Tube | Tube | Bulk |
