VBUS053AZ-HAF-GS08
lmages are for reference only.VBUS053AZ-HAF-GS08
TVS DIODE 5.5VWM 18VC LLP75-7L
Datasheet6-UFDFN Exposed Pad
33,625 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
18V Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount LLP75-7L
VBUS053AZ-HAF-GS08
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Steering (Rail to Rail) |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Breakdown (Min) | 6.5V |
| Voltage - Clamping (Max) @ Ipp | 18V |
| Current - Peak Pulse (10/1000µs) | 3A (8/20µs) |
| Power - Peak Pulse | 36W |
| Power Line Protection | Yes |
| Applications | USB OTG |
| Capacitance @ Frequency | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN Exposed Pad |
| Supplier Device Package | LLP75-7L |
| Base Product Number | VBUS053 |
| Unidirectional Channels | 3 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | VBUS03B1-SD0-G4-08 | VBUS03B1-SD0HG4-08 | VBUS03M1-DD1-G3-08 | VBUS03N1-DD1-G3-08 |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | TVS DIODE 3.3VWM 29VC CLP0603 | TVS DIODE 3.3VWM 18VC CLP0603 | TVS DIODE 3.3VWM 21VC LLP1006-2M | 3.3V;IR=0.1UA;IP=4A;P=90W;CD=0.4 |
| Series | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
