VCAN26A2-03SHE3A18
lmages are for reference only.Payment Methods
Delivery Services
50V Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3
VCAN26A2-03SHE3A18
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Vishay |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 26.5V (Max) |
| Voltage - Breakdown (Min) | 28V |
| Voltage - Clamping (Max) @ Ipp | 50V |
| Current - Peak Pulse (10/1000µs) | 3A (8/20µs) |
| Power - Peak Pulse | 150W |
| Power Line Protection | No |
| Applications | CAN |
| Capacitance @ Frequency | 10pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | VCAN26A2-03SHE3-08 | VCAN26A2-03SHE3-18 | VCAN26A2-03SHE3A08 | VCAN26A2-03S-E3-08 |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 26.5VWM 50VC SOT23 | TVS DIODE 26.5VWM 50VC SOT23 | ESD PROTECTION DIODE SOT23 | TVS DIODE 26.5VWM 50VC SOT23 |
| Series | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay | Vishay General Semiconductor - Diodes Division |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
