VCHA075D-2R2MS6
lmages are for reference only.VCHA075D-2R2MS6
IND SMD 2.2UH AUTO GRADE CHOKE
DatasheetNonstandard
64,149 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.2 µH Unshielded Molded Inductor 8.7 A 11.4mOhm Max Nonstandard
VCHA075D-2R2MS6
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Delta Electronics/Cyntec |
| Series | VCHA075D |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| Type | Molded |
| Material - Core | Metal |
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 8.7 A |
| Current - Saturation (Isat) | 12.7A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 11.4mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 165°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.303" L x 0.283" W (7.70mm x 7.20mm) |
| Height - Seated (Max) | 0.213" (5.40mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | VCHA075D-100MS6 | VCHA075D-150MS6P | VCHA075D-1R5MS6 | VCHA075D-220MS6 |
| Manufacturer | Delta Electronics/Cyntec | Delta Electronics/Cyntec | Delta Electronics/Cyntec | Delta Electronics/Cyntec |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | FIXED IND 10UH 5.2A 38 MOHM SMD | FIXED IND 15UH 3.8A 66 MOHM SMD | IND SMD 1.5UH AUTO GRADE CHOKE | FIXED IND 22UH 3.3A 93.5MOHM SMD |
| Series | Delta Electronics/Cyntec | Delta Electronics/Cyntec | Delta Electronics/Cyntec | Delta Electronics/Cyntec |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
