VEMD5010X01
lmages are for reference only.VEMD5010X01
SENSOR PHOTODIODE 940NM 4SMD
Datasheet4-SMD, No Lead Exposed Pad
87,765 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Photodiode 940nm 100ns 65° 4-SMD, No Lead Exposed Pad
VEMD5010X01
| Category | Sensors, Transducers - Optical Sensors - Photodiodes |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT)--> |
| RoHS Status | ROHS3 Compliant |
| Wavelength | 940nm |
| Color - Enhanced | - |
| Spectral Range | 450nm ~ 1100nm |
| Diode Type | PIN |
| Responsivity @ nm | - |
| Response Time | 100ns |
| Voltage - DC Reverse (Vr) (Max) | 20 V |
| Current - Dark (Typ) | 2nA |
| Active Area | 7.5mm² |
| Viewing Angle | 65° |
| Operating Temperature | -40°C ~ 110°C |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead Exposed Pad |
| Base Product Number | VEMD5010 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | VEMD5010X01-GS15 | VEMD5060X01 | VEMD5060X01-GS15 | VEMD5080X01 |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | SENSOR PHOTODIODE 940NM 4SMD | SENSOR PHOTODIODE 820NM 4SMD | SENSOR PHOTODIODE 820NM 4SMD | SENSOR PHOTODIODE 950NM 4SMD |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT)--> | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT)--> |
