Product CatalogPart Number
VLA503-01
Manufacturer
Powerex Inc.Description
IC GATE DRVR LOW-SIDE MODULE
Datasheet
DatasheetPackage
12-SIP
In Stock
92,357 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
VLA503-01
VLA503-01
lmages are for reference only.Payment Methods
Delivery Services
Low-Side Gate Driver IC Non-Inverting Module
Quick Inquiry
VLA503-01
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Powerex Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Driven Configuration | Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | IGBT |
| Voltage - Supply | 14V ~ 15V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 5A, 5A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 300ns, 300ns |
| Operating Temperature | -20°C ~ 60°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 12-SIP |
| Supplier Device Package | Module |
| Base Product Number | VLA503 |
| Grade | - |
| Qualification | - |
