VLS4015CX-6R8M-H
lmages are for reference only.VLS4015CX-6R8M-H
INDUCTORS FOR POWER CIRCUITS, AU
Datasheet1616 (4040 Metric)
98,365 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
6.8 µH Shielded Drum Core, Wirewound Inductor 1.68 A 204mOhm Max 1616 (4040 Metric)
VLS4015CX-6R8M-H
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TDK Corporation |
| Series | VLS-CX-H |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 6.8 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.68 A |
| Current - Saturation (Isat) | 1.66A |
| Shielding | Shielded |
| DC Resistance (DCR) | 204mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1616 (4040 Metric) |
| Supplier Device Package | 1616 |
| Size / Dimension | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
| Height - Seated (Max) | 0.059" (1.50mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | VLS4015CX-100M-H | VLS4015CX-101M-H | VLS4015CX-150M-H | VLS4015CX-151M-H |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | INDUCTORS FOR POWER CIRCUITS, AU | INDUCTORS FOR POWER CIRCUITS, AU | INDUCTORS FOR POWER CIRCUITS, AU | INDUCTORS FOR POWER CIRCUITS, AU |
| Series | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
