VN9004AJTR
lmages are for reference only.VN9004AJTR
SINGLE CHANNEL HIGH-SIDE DRIVER
Datasheet16-PowerLFSOP (0.154", 3.90mm Width)
99,316 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 108A PowerSSO-16
VN9004AJTR
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | Parallel |
| Voltage - Load | - |
| Voltage - Supply (Vcc/Vdd) | 4V ~ 28V |
| Current - Output (Max) | 108A |
| Rds On (Typ) | 4.2mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Status Flag |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Battery, UVLO |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerSSO-16 |
| Package / Case | 16-PowerLFSOP (0.154", 3.90mm Width) |
| Base Product Number | VN9004 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute |  |
 |
 |
 |
| Part Number | VN9006AJTR | VN9008AJTR | VN9012AJTR | VN9016AJTR |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | SINGLE CHANNEL HIGH-SIDE DRIVER | SINGLE CHANNEL HIGH-SIDE DRIVER | AUTOMOTIVE ANALOG AND POWER | AUTOMOTIVE ANALOG AND POWER |
| Series | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
