VS-36MB05A
lmages are for reference only.VS-36MB05A
BRIDGE RECT 1PHASE 50V 35A D-34
Datasheet4-Square, D-34
13,763 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bridge Rectifier Single Phase Standard 50 V QC Terminal D-34
VS-36MB05A
| Category | Discrete Semiconductor Products - Diodes - Bridge Rectifiers |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 50 V |
| Current - Average Rectified (Io) | 35 A |
| Voltage - Forward (Vf) (Max) @ If | - |
| Current - Reverse Leakage @ Vr | 10 µA @ 1600 V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | QC Terminal |
| Package / Case | 4-Square, D-34 |
| Supplier Device Package | D-34 |
| Base Product Number | 36MB05 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | VS-36MB100A | VS-36MB10A | VS-36MB120A | VS-36MB140A |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | BRIDGE RECT 1PHASE 1KV 35A D-34 | BRIDGE RECT 1PHASE 100V 35A D-34 | BRIDGE RECT 1P 1.2KV 35A D-34 | BRIDGE RECT 1P 1.4KV 35A D-34 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
