VS-MBRD660CT-M3
lmages are for reference only.VS-MBRD660CT-M3
DIODE ARRAY SCHOTTKY 60V 3A DPAK
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
20,242 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Diode Array 1 Pair Common Cathode 60 V 3A Surface Mount TO-252-3, DPAK (2 Leads + Tab), SC-63
VS-MBRD660CT-M3
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Diode Configuration | 1 Pair Common Cathode |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Current - Average Rectified (Io) (per Diode) | 3A |
| Voltage - Forward (Vf) (Max) @ If | 700 mV @ 3 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 100 µA @ 50 V |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252AA (DPAK) |
| Base Product Number | MBRD660 |
| Reverse Recovery Time (trr) | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | VS-MBRD660CTPBF | VS-MBRD660CTTR-M3 | VS-MBRD660CTTRL-M3 | VS-MBRD660CTTRLPBF |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE ARRAY SCHOTTKY 60V 3A DPAK | DIODE ARRAY SCHOTTKY 60V 3A DPAK | DIODE ARRAY SCHOTTKY 60V 3A DPAK | DIODE ARRAY SCHOTTKY 60V 3A DPAK |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
