SCR 800 V 314 A Standard Recovery Chassis, Stud Mount TO-209AB (TO-93)
VS-ST180S08P1V
| Category | Discrete Semiconductor Products - Thyristors - SCRs |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Voltage - Off State | 800 V |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - On State (It (AV)) (Max) | 200 A |
| Current - Hold (Ih) (Max) | 600 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 4200A, 4400A |
| SCR Type | Standard Recovery |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Chassis, Stud Mount |
| Package / Case | TO-209AB, TO-93-4, Stud |
| Supplier Device Package | TO-209AB (TO-93) |
| Voltage - On State (Vtm) (Max) | 1.75 V |
| Current - On State (It (RMS)) (Max) | 314 A |
| Current - Off State (Max) | 30 mA |
| Base Product Number | ST180 |
| Product Attribute |  |
 |
 |
 |
| Part Number | VS-ST180S08P0V | VS-ST180C04C0 | VS-ST180C12C1 | VS-ST180C16C0 |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SCR 800V 314A TO209AB | SCR 400V 660A A-PUK | SCR 1.2KV 660A A-PUK | SCR 1.6KV 660A A-PUK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
