WCL3225-270-R
lmages are for reference only.WCL3225-270-R
FIXED IND 27UH 180MA 2.7 OHM SMD
Datasheet1210 (3225 Metric)
46,269 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
27 µH Unshielded Drum Core, Wirewound Inductor 180 mA 2.7Ohm Max 1210 (3225 Metric)
WCL3225-270-R
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | WCL3225 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ceramic |
| Inductance | 27 µH |
| Tolerance | ±5% |
| Current Rating (Amps) | 180 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 2.7Ohm Max |
| Q @ Freq | 10 @ 2.52MHz |
| Frequency - Self Resonant | 18MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 2.52 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) |
| Supplier Device Package | 1210 |
| Size / Dimension | 0.138" L x 0.114" W (3.50mm x 2.90mm) |
| Height - Seated (Max) | 0.089" (2.25mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | WCL3225-271-R | WCL3225-271-R | WCL3225-100-R | WCL3225-101-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | |
| Description | FIXED IND 270UH 60MA 18 OHM SMD | FIXED IND 270UH 60MA 18 OHM SMD | FIXED IND 10UH 300MA 1 OHM SMD | FIXED IND 100UH 95MA 6.8 OHM SMD |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
