Product CatalogPart Number
WP86SD-S080VA1-R20000
Manufacturer
JAE ElectronicsDescription
CONN RCPT 80 POS 0.25MM PITCH 0.
Datasheet
DatasheetPackage
-
In Stock
27,872 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
WP86SD-S080VA1-R20000
WP86SD-S080VA1-R20000
lmages are for reference only.Payment Methods
Delivery Services
80 Position Connector Receptacle, Center Strip Contacts Surface Mount Gold
Quick Inquiry
WP86SD-S080VA1-R20000
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Arrays-Edge Type-Mezzanine Board to Board |
| Manufacturer | JAE Electronics |
| Series | WP86SD |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle, Center Strip Contacts |
| Number of Positions | 80 |
| Pitch | 0.010" (0.25mm) |
| Number of Rows | 4 |
| Mounting Type | Surface Mount |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 2.00µin (0.051µm) |
| Mated Stacking Heights | - |
| Height Above Board | 0.020" (0.50mm) |
| Base Product Number | - |
