XCL238E1F3D2-G
lmages are for reference only.XCL238E1F3D2-G
HISAT-COT 1.5A INDUCTOR BUILT-IN
Datasheet9-PowerTFQFN
90,054 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 1.55V 1.5A 2.5V - 5.5V Input
XCL238E1F3D2-G
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Torex Semiconductor Ltd |
| Series | XCL238 |
| Packaging | Case |
| RoHS Status | ROHS3 Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.5V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output 1 | 1.55V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.5A |
| Power (Watts) | 2.325 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output |
| Operating Temperature | -40°C ~ 105°C |
| Efficiency | 89% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 9-PowerTFQFN |
| Size / Dimension | 0.13" L x 0.10" W x 0.04" H (3.2mm x 2.5mm x 1.0mm) |
| Supplier Device Package | USP-9B01 |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | - |
| Product Attribute | |
|
|
|
| Part Number | XCL238E103D2-G | XCL238E113D2-G | XCL238E123D2-G | XCL238E133D2-G |
| Manufacturer | Torex Semiconductor Ltd | Torex Semiconductor Ltd | Torex Semiconductor Ltd | Torex Semiconductor Ltd |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | HISAT-COT 1.5A INDUCTOR BUILT-IN | HISAT-COT 1.5A INDUCTOR BUILT-IN | HISAT-COT 1.5A INDUCTOR BUILT-IN | HISAT-COT 1.5A INDUCTOR BUILT-IN |
| Series | Torex Semiconductor Ltd | Torex Semiconductor Ltd | Torex Semiconductor Ltd | Torex Semiconductor Ltd |
| Packaging | Case | Case | Case | Case |
