XF2H-1815-1
Manufacturer
Omron Electronics Inc-EMC DivDescription
CONN FPC 18POS 0.5MM SMT
Datasheet
DatasheetPackage
-
In Stock
12,123 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XF2H-1815-1
XF2H-1815-1
lmages are for reference only.Payment Methods
Delivery Services
18 Position FPC Connector Contacts, Top and Bottom 0.020" (0.50mm) Surface Mount, Right Angle
Quick Inquiry
XF2H-1815-1
Specifications
| Category | Connectors, Interconnects - FFC-FPC Flat Flexible Connectors - FFC-FPC Flat Flexible Connector Assemblies |
| Manufacturer | Omron Electronics Inc-EMC Div |
| Series | XF2H |
| Packaging | Cut Tape (CT) |
| RoHS Status | RoHS non-compliant |
| Flat Flex Type | FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top and Bottom |
| Number of Positions | 18 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.079" (2.00mm) |
| Locking Feature | Rotary Lock, Backlock |
| Cable End Type | Straight |
| Contact Material | Copper Alloy |
| Contact Finish | Tin Alloy |
| Housing Material | Polyamide (PA46), Nylon 4/6 |
| Actuator Material | Liquid Crystal Polymer (LCP) |
| Features | Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -30°C ~ 85°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 0.5A |
| Contact Finish Thickness | 78.7µin (2.00µm) |
| Housing Color | Natural |
| Actuator Color | Black |
| Mating Cycles | 20 |
| Base Product Number | - |
