XFL3012-563MEC
Manufacturer
CoilcraftDescription
XFL3012-563MEC
Datasheet
DatasheetPackage
1212 (3030 Metric)
In Stock
46,574 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XFL3012-563MEC
XFL3012-563MEC
lmages are for reference only.Payment Methods
Delivery Services
56 µH Shielded Molded Inductor 320 mA 1.52Ohm Max 1212 (3030 Metric)
Quick Inquiry
XFL3012-563MEC
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Coilcraft |
| Series | XFL3012 |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Type | Molded |
| Material - Core | Metal Composite |
| Inductance | 56 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 320 mA |
| Current - Saturation (Isat) | 300mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 1.52Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 12.1MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1212 (3030 Metric) |
| Supplier Device Package | 1212 |
| Size / Dimension | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Height - Seated (Max) | 0.051" (1.30mm) |
| Base Product Number | - |
