Product CatalogPart Number
XGL1060-222MEC
Manufacturer
CoilcraftDescription
FIXED IND 2.2UH 25.3A 4.3MOHM SM
Datasheet
DatasheetPackage
Nonstandard
In Stock
60,159 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XGL1060-222MEC
XGL1060-222MEC
lmages are for reference only.Payment Methods
Delivery Services
2.2 µH Shielded Molded Inductor 25.3 A 4.3mOhm Max Nonstandard
Quick Inquiry
XGL1060-222MEC
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Coilcraft |
| Series | XGL1060 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Molded |
| Material - Core | Metal Composite |
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 25.3 A |
| Current - Saturation (Isat) | 31A |
| Shielding | Shielded |
| DC Resistance (DCR) | 4.3mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 25MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.445" L x 0.394" W (11.30mm x 10.00mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Base Product Number | - |
