Product CatalogPart Number
XP2314GN
Manufacturer
YAGEO XSEMIDescription
MOSFET N-CH 20V 3.5A SOT23
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
40,925 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XP2314GN
XP2314GN
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 20 V 3.5A (Ta) 830mW (Ta) Surface Mount SOT-23
Quick Inquiry
XP2314GN
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | YAGEO XSEMI |
| Series | XP2314 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 3.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Rds On (Max) @ Id, Vgs | 75mOhm @ 3.5A, 4.5V |
| Vgs(th) (Max) @ Id | 1.2V @ 250µA |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 370 pF @ 20 V |
| FET Feature | - |
| Power Dissipation (Max) | 830mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 7 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | XP2318GEN | XP231N02013R-G | XP231N0201TR-G | XP231P02013R-G |
| Manufacturer | YAGEO XSEMI | Torex Semiconductor Ltd | Torex Semiconductor Ltd | Torex Semiconductor Ltd |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 30V 500MA SOT23 | MOSFET N-CH 30V 200MA SOT323-3 | MOSFET N-CH 30V 200MA | MOSFET P-CH 30V 200MA SOT323-3 |
| Series | XP2318 | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
