XP3N5R0AYT
Manufacturer
YAGEO XSEMIDescription
MOSFET N-CH 30V 20A 63.5A PMPAK
Datasheet
DatasheetPackage
8-PowerDFN
In Stock
61,770 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XP3N5R0AYT
XP3N5R0AYT
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 20A (Ta), 63.5A (Tc) 3.12W (Ta) Surface Mount PMPAK® 3 x 3
Quick Inquiry
XP3N5R0AYT
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | YAGEO XSEMI |
| Series | XP3N5R0A |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Ta), 63.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 5mOhm @ 19A, 10V |
| Vgs(th) (Max) @ Id | 2.3V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2800 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 3.12W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PMPAK® 3 x 3 |
| Package / Case | 8-PowerDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 64 nC @ 10 V |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | XP3N5R0AMT | XP3N5R0H | XP3N5R0M | XP3N5R0MT |
| Manufacturer | YAGEO XSEMI | YAGEO XSEMI | YAGEO XSEMI | YAGEO XSEMI |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 30V 25A 63.5A PMPAK | MOSFET N-CH 30V 62A TO252 | MOSFET N-CH 30V 17.4A 8SO | MOSFET N CH 30V 24.7A PMPAK5X6 |
| Series | XP3N5R0A | XP3N5R0 | XP3N5R0 | XP3N5R0 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
