Product CatalogPart Number
XP3N9R5MT
Manufacturer
YAGEO XSEMIDescription
MOSFET N CH 30V 17.7A PMPAK5X
Datasheet
DatasheetPackage
8-PowerLDFN
In Stock
18,073 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XP3N9R5MT
XP3N9R5MT
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 17.7A (Ta), 37.8A (Tc) 5W (Ta), 22.7W (Tc) Surface Mount 8-PMPAK (5x6)
Quick Inquiry
XP3N9R5MT
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | YAGEO XSEMI |
| Series | XP3N9R5 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 17.7A (Ta), 37.8A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 9.5mOhm @ 9.5A, 10V |
| Vgs(th) (Max) @ Id | 2.3V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1600 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 5W (Ta), 22.7W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-PMPAK (5x6) |
| Package / Case | 8-PowerLDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 38.4 nC @ 10 V |
| Grade | - |
| Qualification | - |
