XW4N-12D1-S

XW4N-12D1-S

XW4N-12D1-S

lmages are for reference only.
  • Part Number

    XW4N-12D1-S

  • Manufacturer

    Omron Electronics Inc-EMC Div
  • Description

    SOCKET,SINGLE-ROW,,TIN REFLOW,

  • Datasheet

    DatasheetDatasheet
  • Package

    -

  • In Stock

    81,759 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

12 Position Terminal Block Plug, Female Sockets 0.138" (3.50mm) 180° Free Hanging (In-Line)

Quick Inquiry

XW4N-12D1-S

Get the Price Now!

Specifications

Category Connectors, Interconnects - Terminal Blocks - Headers-Plugs and Sockets
Manufacturer Omron Electronics Inc-EMC Div
Series XW4N
Packaging Tray
RoHS Status RoHS Compliant
Base Product Number -
Type Plug, Female Sockets
Number of Positions 12
Positions Per Level 12
Number of Levels 1
Pitch 0.138" (3.50mm)
Header Orientation -
Plug Wire Entry 180°
Termination Style Screwless - Leg Spring, Push-In Spring
Mounting Type Free Hanging (In-Line)
Current - IEC 8A
Voltage - IEC 160 V
Wire Gauge or Range - AWG 16-24 AWG
Wire Gauge or Range - mm² 0.2-1.5mm²
Color Black
Operating Temperature -40°C ~ 100°C
Contact Mating Finish Tin
Features Lever Actuated
Material Flammability Rating UL94 V-0
Ingress Protection -
Screw Size -
Torque - Screw -
Wire Strip Length 9.5mm
Contact Material Copper Alloy
Housing Material Polyamide (PA), Nylon
Contact Tail Length -
Insulation Height 0.423" (10.75mm)
Current - UL 8 A
Voltage - UL 300 V

Parts with Similar Specifications

Product Attribute XW4N-12D1-A XW4N-12D2-A XW4N-12D2-S XW4N-02D1-A
Part Number XW4N-12D1-A XW4N-12D2-A XW4N-12D2-S XW4N-02D1-A
Manufacturer Omron Electronics Inc-EMC Div Omron Electronics Inc-EMC Div Omron Electronics Inc-EMC Div Omron Electronics Inc-EMC Div
RoHS Status RoHS Compliant RoHS Compliant RoHS Compliant RoHS Compliant
Description SOCKET,SINGLE-ROW,,GOLD, SOCKET,DOUBLE-ROW,,GOLD, SOCKET,DOUBLE-ROW,,GOLD, SOCKET,SINGLE-ROW,,GOLD,
Series XW4N XW4N XW4N XW4N
Packaging Tray Tray Tray Tray
