ZM4732A
lmages are for reference only.ZM4732A
DIODE ZENER 4.7V 1W MELF
DatasheetDO-213AB, MELF
31,978 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Zener Diode 4.7 V 1 W ±5% Surface Mount MELF
ZM4732A
| Category | Discrete Semiconductor Products - Diodes - Zener |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Voltage - Zener (Nom) (Vz) | 4.7 V |
| Tolerance | ±5% |
| Power - Max | 1 W |
| Impedance (Max) (Zzt) | 8 Ohms |
| Current - Reverse Leakage @ Vr | 10 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | - |
| Operating Temperature | -65°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | DO-213AB, MELF |
| Supplier Device Package | MELF |
| Base Product Number | ZM4732 |
| Product Attribute | |
 |
 |
|
| Part Number | ZM4732A L0G | ZM4732A-GS08 | ZM4732A-GS18 | ZM4728A |
| Manufacturer | Taiwan Semiconductor Corporation | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DIODE ZENER 4.7V 1W MELF | DIODE ZENER 4.7V 1W DO213AB | DIODE ZENER 4.7V 1W DO213AB | DIODE ZENER 3.3V 1W MELF |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
