Product CatalogPart Number
ZUW152412-G
Manufacturer
Cosel USA, Inc.Description
DC DC CONVERTER +/-12V 24V 16W
Datasheet
DatasheetPackage
7-DIP Module
In Stock
17,909 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ZUW152412-G
ZUW152412-G
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 2 Output 12V -12V 650mA, 650mA 18V - 36V Input
Quick Inquiry
ZUW152412-G
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Cosel USA, Inc. |
| Series | ZUW (15W) |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 650mA, 650mA |
| Power (Watts) | 16 W |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -20°C ~ 71°C (With Derating) |
| Efficiency | 83% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 7-DIP Module |
| Size / Dimension | 1.97" L x 1.77" W x 0.33" H (50.0mm x 45.0mm x 8.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | ZUW152412 |
| Voltage - Isolation | 500 V |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | ZUW152412 | ZUW152415 | ZUW150512 | ZUW150515 |
| Manufacturer | Cosel USA, Inc. | Cosel USA, Inc. | Cosel USA, Inc. | Cosel USA, Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER +/-12V | DC DC CONVERTER +/-15V | DC DC CONVERTER +/-12V | DC DC CONVERTER +/-15V |
| Series | Cosel USA, Inc. | Cosel USA, Inc. | Cosel USA, Inc. | Cosel USA, Inc. |
| Packaging | Box | Box | Box | Box |
