Power Switch/Driver 1:1 N-Channel 1.5A 8-SO-EP (Type E)
ZXMS81200SP-13
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | Logic |
| Voltage - Load | 28V ~ 28V |
| Voltage - Supply (Vcc/Vdd) | 5V ~ Not Required |
| Current - Output (Max) | 1.5A |
| Rds On (Typ) | 200mOhm |
| Input Type | Non-Inverting |
| Features | Slew Rate Controlled |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Load, Over Temperature, Over Voltage, Reverse Battery, Short Circuit, UVLO |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SO-EP (Type E) |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ZXMS81200SPQ-13 | ZXMS6001N3QTA | ZXMS6001N3TA | ZXMS6002GQTA |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | HIGH SIDE INTELLIFET SO-8EP T&R | IC PWR DRIVER N-CHAN 1:1 SOT223 | IC PWR DRIVER N-CHAN 1:1 SOT223 | IC PWR DRIVER N-CHAN 1:1 SOT223 |
| Series | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
