Image | Part Number | Manufacturer | Description | Package | Stock | Quantity | Packaging | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Package / Case | Supplier Device Package | Size / Dimension | Height - Seated (Max) | Base Product Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
  | Taiyo Yuden | FIXED IND 120UH 1A 250 MOHM TH
| Package: Radial, Vertical Cylinder | Stock41,653 | Tape & Box (TB) | - | Ferrite | 120 µH | ±10% | 1 A | - | Unshielded | 250mOhm Max | 40 @ 796kHz | 3.2MHz | - | -25°C ~ 105°C | 796 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.433" Dia (11.00mm) | 0.551" (14.00mm) | - | ||
 | Taiyo Yuden | FIXED IND 12UH 15MA 900 MOHM SMD
| Package: 0805 (2012 Metric) | Stock73,242 | Tape & Reel (TR) | Multilayer | - | 12 µH | ±10% | 15 mA | - | Unshielded | 900mOhm Max | 50 @ 2MHz | 22MHz | - | -40°C ~ 85°C | 2 MHz | - | Surface Mount | 0805 (2012 Metric) | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) | - | ||
| | Taiyo Yuden | FIXED IND 390UH 55MA 22 OHM TH
| Package: Axial | Stock26,009 | Bulk | - | - | 390 µH | ±10% | 55 mA | - | Unshielded | 22Ohm Max | 50 @ 796kHz | 2.4MHz | - | -25°C ~ 105°C | 796 kHz | - | Through Hole | Axial | - | 0.102" Dia x 0.276" L (2.60mm x 7.00mm) | - | - | ||
| | Taiyo Yuden | FIXED IND 1UH 1A 140 MOHM SMD
| Package: 0805 (2012 Metric) | Stock18,670 | Tape & Reel (TR) | Multilayer | Ferrite | 1 µH | ±20% | 1 A | - | Unshielded | 140mOhm Max | - | - | - | -40°C ~ 85°C | 1 MHz | - | Surface Mount | 0805 (2012 Metric) | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.039" (1.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 1UH 3.3A 36 MOHM TH
| Package: Axial | Stock85,185 | Tape & Box (TB) | Wirewound | - | 1 µH | ±10% | 3.3 A | 5.6A | Unshielded | 36mOhm Max | - | - | - | -25°C ~ 105°C | 7.96 MHz | - | Through Hole | Axial | - | 0.173" Dia x 0.315" L (4.40mm x 8.00mm) | - | - | ||
 | Taiyo Yuden | FIXED IND 2.9UH 7.3A 12.09 MOHM
| Package: Nonstandard | Stock57,986 | Tape & Reel (TR) | Wirewound | Ferrite | 2.9 µH | ±30% | 7.3 A | 8.2A | Shielded | 9.3mOhm | - | 29MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.394" L x 0.386" W (10.00mm x 9.80mm) | 0.197" (5.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 6.8MH 250MA 5.6 OHM TH
| Package: Radial, Vertical Cylinder | Stock83,437 | Tape & Box (TB) | - | Ferrite | 6.8 mH | ±5% | 250 mA | - | Unshielded | 5.6Ohm Max | 30 @ 252kHz | 380kHz | - | -25°C ~ 105°C | 252 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.551" Dia (14.00mm) | 0.669" (17.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 3.7NH 240MA 350MOHM SM
| Package: 01005 (0402 Metric) | Stock25,580 | Tape & Reel (TR) | Multilayer | Ceramic | 3.7 nH | ±0.2nH | 240 mA | - | Unshielded | 350mOhm Max | 11 @ 500MHz | 6.5GHz | - | -55°C ~ 125°C | 500 MHz | - | Surface Mount | 01005 (0402 Metric) | 01005 (0402 Metric) | 0.016" L x 0.008" W (0.40mm x 0.20mm) | 0.009" (0.23mm) | - | ||
| | Taiyo Yuden | FIXED IND 4.7UH 600MA 615MOHM SM
| Package: 0805 (2012 Metric) | Stock62,960 | Tape & Reel (TR) | Wirewound | Metal | 4.7 µH | ±20% | 600 mA | 600mA | Unshielded | 615mOhm Max | - | - | - | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 0805 (2012 Metric) | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.039" (1.00mm) | - | ||
 | Taiyo Yuden | FIXED IND 470UH 380MA 1.3 OHM TH
| Package: Radial, Vertical Cylinder | Stock42,236 | Bulk | - | Ferrite | 470 µH | ±10% | 380 mA | - | Unshielded | 1.3Ohm Max | 25 @ 796kHz | 2.4MHz | - | -25°C ~ 105°C | 796 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.354" Dia (9.00mm) | 0.374" (9.50mm) | - | ||
| | Taiyo Yuden | FIXED IND 470UH 240MA 6.3 OHM TH
| Package: Axial | Stock45,450 | Cut Tape (CT)-->Tape & Box (TB) | Wirewound | - | 470 µH | ±10% | 240 mA | 270mA | Unshielded | 6.3Ohm Max | - | - | - | -25°C ~ 105°C | 796 kHz | - | Through Hole | Axial | - | 0.173" Dia x 0.315" L (4.40mm x 8.00mm) | - | - | ||
 | Taiyo Yuden | FIXED IND 3.3UH 6.49A 12MOHM SMD
| Package: Nonstandard | Stock54,128 | Tape & Reel (TR) | Wirewound | Ferrite | 3.3 µH | ±30% | 6.49 A | 8.5A | Shielded | 9.7mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.398" L x 0.398" W (10.10mm x 10.10mm) | 0.230" (5.85mm) | - | ||
 | Taiyo Yuden | FIXED IND 220UH 1.18A 324MOHM SM
| Package: Nonstandard | Stock35,005 | Tape & Reel (TR) | Wirewound | Ferrite | 220 µH | ±20% | 1.18 A | 1A | Shielded | 270mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.230" (5.85mm) | - | ||
 | Taiyo Yuden | FIXED IND 2.2UH 890MA 180MOHM SM
| Package: Nonstandard | Stock59,678 | Tape & Reel (TR)-->Cut Tape (CT) | Drum Core, Wirewound | Ferrite | 2.2 µH | ±30% | 890 mA | 1.15A | Shielded | 180mOhm Max | - | 73MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.039" (1.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 22UH 2.8A 51.6MOHM SMD
| Package: Nonstandard | Stock29,321 | Tape & Reel (TR) | Wirewound | - | 22 µH | ±20% | 2.8 A | 3.37A | Shielded | 51.6mOhm Max | - | 11.3MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.398" L x 0.398" W (10.10mm x 10.10mm) | 0.230" (5.85mm) | - | ||
| | Taiyo Yuden | FIXED IND 33 UH 1.7A 0.13 OHM
| Package: 3131 (8080 Metric) | Stock66,920 | Tape & Reel (TR) | Wirewound | Ferrite | 33 µH | ±20% | 1.7 A | 2A | Unshielded | 100mOhm | - | 12MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 (8080 Metric) | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.157" (4.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 10NH 300MA 260MOHM SMD
| Package: 0603 (1608 Metric) | Stock61,834 | Tape & Reel (TR) | Multilayer | Ferrite | 10 nH | ±10% | 300 mA | - | Unshielded | 260mOhm Max | 12 @ 100MHz | 3.4GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 0603 (1608 Metric) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) | - | ||
| | Taiyo Yuden | FIXED IND 47MH 50MA 96 OHM TH
| Package: Radial, Vertical Cylinder | Stock31,667 | Bulk | - | Ferrite | 47 mH | ±5% | 50 mA | - | Unshielded | 96Ohm Max | 40 @ 79.6kHz | 120kHz | - | -25°C ~ 105°C | 1 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.433" Dia (11.00mm) | 0.551" (14.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 120NH 300MA 950MOHM SM
| Package: 0805 (2012 Metric) | Stock72,805 | Tape & Reel (TR) | Multilayer | Ferrite | 120 nH | ±5% | 300 mA | - | Unshielded | 950mOhm Max | 13 @ 50MHz | 500MHz | - | -40°C ~ 85°C | 50 MHz | - | Surface Mount | 0805 (2012 Metric) | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.047" (1.20mm) | - | ||
| | Taiyo Yuden | FIXED IND 150UH 0.39A 2.364 OHM
| Package: 1616 (4040 Metric) | Stock35,863 | Tape & Reel (TR) | Wirewound | Ferrite | 150 µH | ±20% | 250 mA | 390mA | Unshielded | 2.364Ohm Max | - | 7MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 1616 (4040 Metric) | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.079" (2.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 22UH 80MA 1.7 OHM SMD
| Package: 0805 (2012 Metric) | Stock81,959 | Tape & Reel (TR) | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 80 mA | - | Unshielded | 1.7Ohm | - | 16MHz | - | -25°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0805 (2012 Metric) | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) | - | ||
| | Taiyo Yuden | FIXED IND 15UH 3A 45.8 MOHM SMD
| Package: Nonstandard | Stock58,933 | Tape & Reel (TR) | Wirewound | Ferrite | 15 µH | ±20% | 3 A | 3.44A | Shielded | 38.1mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | Nonstandard | - | 0.398" L x 0.398" W (10.10mm x 10.10mm) | 0.191" (4.85mm) | - | ||
| | Taiyo Yuden | FIXED IND 1.5 UH 4.1A 0.041 OHM
| Package: 1616 (4040 Metric) | Stock99,129 | Tape & Reel (TR) | Wirewound | Metal | 1.5 µH | ±20% | 4.1 A | 7A | Unshielded | 41mOhm Max | - | - | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 (4040 Metric) | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.079" (2.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 330NH 7.8A 13 MOHM SMD
| Package: 1616 (4040 Metric) | Stock33,419 | Tape & Reel (TR) | Wirewound | Metal | 330 nH | ±30% | 7.8 A | 16A | Unshielded | 13mOhm Max | - | - | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 (4040 Metric) | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.079" (2.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 1.5UH 220MA 1.3OHM SMD
| Package: 1008 (2520 Metric) | Stock77,701 | Tape & Reel (TR) | Wirewound | - | 1.5 µH | ±5% | 220 mA | - | Unshielded | 1.3Ohm Max | 30 @ 7.96MHz | 135MHz | - | -40°C ~ 85°C | 7.96 MHz | - | Surface Mount | 1008 (2520 Metric) | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.079" (2.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 47UH 2.1A 81 MOHM TH
| Package: Radial, Vertical Cylinder | Stock23,969 | Bulk | - | Ferrite | 47 µH | ±20% | 2.1 A | - | Shielded | 81mOhm Max | - | - | - | -25°C ~ 105°C | 2.52 MHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.512" Dia (13.00mm) | 0.630" (16.00mm) | - | ||
 | Taiyo Yuden | FIXED IND 1.2NH 430MA 110MOHM SM
| Package: 01005 (0402 Metric) | Stock28,817 | Tape & Reel (TR)-->Cut Tape (CT) | Multilayer | Ceramic | 1.2 nH | ±0.1nH | 430 mA | - | Unshielded | 110mOhm Max | 12 @ 500MHz | 10GHz | - | -55°C ~ 125°C | 500 MHz | - | Surface Mount | 01005 (0402 Metric) | 01005 (0402 Metric) | 0.016" L x 0.008" W (0.40mm x 0.20mm) | 0.009" (0.23mm) | - | ||
| | Taiyo Yuden | FIXED IND 6.8MH 92MA 18 OHM TH
| Package: Radial, Vertical Cylinder | Stock52,719 | Bulk | - | Ferrite | 6.8 mH | ±5% | 92 mA | - | Unshielded | 18Ohm Max | 65 @ 252kHz | 610kHz | - | -25°C ~ 105°C | 252 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.354" Dia (9.00mm) | 0.374" (9.50mm) | - | ||
| | Taiyo Yuden | FIXED IND 1MH 860MA 740 MOHM TH
| Package: Radial, Vertical Cylinder | Stock73,395 | Bulk | - | Ferrite | 1 mH | ±5% | 860 mA | - | Unshielded | 740mOhm Max | 20 @ 252kHz | 840kHz | - | -25°C ~ 105°C | 252 kHz | - | Through Hole | Radial, Vertical Cylinder | - | 0.669" Dia (17.00mm) | 0.827" (21.00mm) | - | ||
| | Taiyo Yuden | FIXED IND 0.47 UH 2.2A 0.046 OHM
| Package: Nonstandard | Stock21,443 | Tape & Reel (TR) | Wirewound | Metal | 470 nH | ±20% | 2.2 A | 3.5A | Unshielded | 46mOhm Max | - | - | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | Nonstandard | - | 0.079" L x 0.079" W (2.00mm x 2.00mm) | 0.039" (1.00mm) | - | ||
 | Taiyo Yuden | FIXED IND 100UH 340MA 1.82OHM SM
| Package: 1210 (3225 Metric) | Stock32,867 | Tape & Reel (TR)-->Cut Tape (CT) | Wirewound | Ferrite | 100 µH | ±10% | 340 mA | 270mA | Unshielded | 1.82Ohm Max | - | 6MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 1210 (3225 Metric) | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.106" (2.70mm) | - | ||
| | Taiyo Yuden | FIXED IND 4.7UH 900MA 200MOHM SM
| Package: 0806 (2016 Metric) | Stock50,305 | Tape & Reel (TR) | Multilayer | Ferrite | 4.7 µH | ±20% | 900 mA | - | Unshielded | 200mOhm Max | - | - | - | -40°C ~ 85°C | 1 MHz | - | Surface Mount | 0806 (2016 Metric) | 0806 (2016 Metric) | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.039" (1.00mm) | - |
