1-1617036-5
lmages are for reference only.1-1617036-5
RELAY GEN PURPOSE DPDT 4A 5V
Datasheet-
32,749 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) 5VDC Coil Through Hole
1-1617036-5
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | HFW4A, CII |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 4 A |
| Switching Voltage | - |
| Load - Max Switching | - |
| Coil Current | 185 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | 2.7 VDC |
| Must Release Voltage | 0.29 VDC |
| Operate Time | 4 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | Silver Alloy |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 27 Ohms |
| Base Product Number | 1617036 |
| Product Attribute |  |
 |
|
 |
| Part Number | 1-1617036-0 | 1-1617036-6 | 1-1617036-7 | 1-1617037-8 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | HFW4A1201G00 = 2100 HFW 4A REL | RELAY GEN PURPOSE DPDT 4A 26.5V | HFW4A1201S05 = HFW 4A RELAY | RELAY GEN PURPOSE DPDT 5A 24V |
| Series | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| Packaging | Bulk | Bulk | Bulk | Bulk |
