Product Catalog

110IMX7-12-12-8

110IMX7-12-12-8

110IMX7-12-12-8

lmages are for reference only.
  • Part Number

    110IMX7-12-12-8

  • Manufacturer

    Bel Power Solutions
  • Description

    DC DC CONVERTER 12V 12V 7W

  • Datasheet

    DatasheetDatasheet
  • Package

    14-DIP Module

  • In Stock

    44,582 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

Isolated Module, Conformal Coated DC DC Converter 2 Output 12V 12V 300mA, 300mA 60V - 150V Input

Quick Inquiry

110IMX7-12-12-8

Get the Price Now!

Specifications

Category Power Supplies - Board Mount - DC DC Converters -
Manufacturer Bel Power Solutions
Series Melcher IMX7 (7W)
Packaging Bulk
RoHS Status ROHS3 Compliant
Type Isolated Module, Conformal Coated
Number of Outputs 2
Voltage - Input (Min) 60V
Voltage - Input (Max) 150V
Voltage - Output 1 12V
Voltage - Output 2 12V
Voltage - Output 3 -
Voltage - Output 4 -
Current - Output (Max) 300mA, 300mA
Power (Watts) 7 W
Applications ITE (Commercial), Railway
Features Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Operating Temperature -40°C ~ 85°C
Efficiency 80%
Grade -
Qualification -
Mounting Type Through Hole
Package / Case 14-DIP Module
Size / Dimension 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.4mm)
Supplier Device Package -
Control Features -
Approval Agency -
Standard Number -
Base Product Number 110IMX7
Voltage - Isolation 2.5 kV

Parts with Similar Specifications

Product Attribute 110IMX7-12-12-8G 110IMX7-12-12-8G 110IMX7-15-15-8G 110IMX35D05D05-8
Part Number 110IMX7-12-12-8G 110IMX7-12-12-8G 110IMX7-15-15-8G 110IMX35D05D05-8
Manufacturer Bel Power Solutions Bel Power Solutions Bel Power Solutions Bel Power Solutions
RoHS Status ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant
Description DC DC CONVERTER 12V 12V 7.2W DC DC CONVERTER 12V 12V 7.2W DC DC CONVERTER 15V 15V 7W DC DC CONVERTER 5V 5V 5V 35W
Series Bel Power Solutions Bel Power Solutions Bel Power Solutions Bel Power Solutions
Packaging Bulk Bulk Bulk Bulk
