110IMY15-03-8RG-G
lmages are for reference only.110IMY15-03-8RG-G
DC DC CONVERTER 3.3V 15W
Datasheet17-DIP Module, 6 Leads
90,787 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module, Conformal Coated DC DC Converter 1 Output 3.3V 4.5A 50V - 150V Input
110IMY15-03-8RG-G
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Bel Power Solutions |
| Series | Melcher IMY15 (15W) |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module, Conformal Coated |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 50V |
| Voltage - Input (Max) | 150V |
| Voltage - Output 1 | 3.3V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 4.5A |
| Power (Watts) | 15 W |
| Applications | ITE (Commercial), Railway |
| Features | OCP, OTP, OVP, SCP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 82% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 17-DIP Module, 6 Leads |
| Size / Dimension | 2.00" L x 1.60" W x 0.41" H (50.8mm x 40.6mm x 10.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | 110IMY15 |
| Voltage - Isolation | 4.2 kV |
| Product Attribute |  |
 |
|
|
| Part Number | 110IMY15-05-05-8 | 110IMY15-05-05-8G | 110IMY15-05-8R | 110IMY15-05-8RG |
| Manufacturer | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 5V 5V 15W | DC DC CONVERTER 5V 5V 15W | DC DC CONVERTER 5.1V 15W | DC DC CONVERTER 5.1V 15W |
| Series | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions | Bel Power Solutions |
| Packaging | Bulk | Bulk | Bulk | Bulk |
