Product CatalogPart Number
2-282828-4
Manufacturer
TE Connectivity AMP ConnectorsDescription
TERM BLOCK HDR 4POS VERT 10.16MM
Datasheet
DatasheetPackage
-
In Stock
86,768 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
2-282828-4
2-282828-4
lmages are for reference only.Payment Methods
Delivery Services
4 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.400" (10.16mm) Vertical Through Hole
Quick Inquiry
2-282828-4
Specifications
| Category | Connectors, Interconnects - Terminal Blocks - Headers-Plugs and Sockets |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | Buchanan |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | 282828 |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Number of Levels | 1 |
| Pitch | 0.400" (10.16mm) |
| Header Orientation | Vertical |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | - |
| Voltage - IEC | - |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Color | Black |
| Operating Temperature | -40°C ~ 110°C |
| Contact Mating Finish | Tin |
| Features | - |
| Material Flammability Rating | UL94 V-0 |
| Ingress Protection | - |
| Screw Size | - |
| Torque - Screw | - |
| Wire Strip Length | - |
| Contact Material | Copper Alloy |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Tail Length | 0.138" (3.50mm) |
| Insulation Height | 0.329" (8.36mm) |
| Current - UL | 15 A |
| Voltage - UL | 600 V |
Parts with Similar Specifications
| Product Attribute | |
|
|
|
| Part Number | 2-282822-0 | 2-282822-1 | 2-282822-2 | 2-282822-3 |
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TERM BLOCK HDR 20POS VERT 5MM | TERM BLOCK HDR 21POS VERT 5MM | TERM BLOCK HDR 22POS VERT 5MM | TERM BLOCK HDR 23POS VERT 5MM |
| Series | Buchanan | Buchanan | Buchanan | Buchanan |
| Packaging | Bulk | Bulk | Bulk | Bulk |
