Product CatalogPart Number
2-282830-6
Manufacturer
TE Connectivity AMP ConnectorsDescription
TERM BLOCK PLUG 25POS 90DEG 5MM
Datasheet
DatasheetPackage
-
In Stock
70,008 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
2-282830-6
2-282830-6
lmages are for reference only.Payment Methods
Delivery Services
25 Position Terminal Block Plug for Unshrouded Header 0.197" (5.00mm) 90° Free Hanging (In-Line)
Quick Inquiry
2-282830-6
Specifications
| Category | Connectors, Interconnects - Terminal Blocks - Headers-Plugs and Sockets |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | Buchanan |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | 282830 |
| Type | Plug for Unshrouded Header |
| Number of Positions | 25 |
| Positions Per Level | 25 |
| Number of Levels | 1 |
| Pitch | 0.197" (5.00mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Screw - Rising Cage Clamp |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Wire Gauge or Range - AWG | 12-30 AWG |
| Wire Gauge or Range - mm² | 0.05-2mm² |
| Color | Green |
| Operating Temperature | -40°C ~ 110°C |
| Contact Mating Finish | Tin |
| Features | Side Stacking |
| Material Flammability Rating | UL94 V-0 |
| Ingress Protection | - |
| Screw Size | M3 |
| Torque - Screw | 0.68 Nm (6 Lb-In) |
| Wire Strip Length | 6-7.5mm |
| Contact Material | Phosphor Bronze |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Contact Tail Length | - |
| Insulation Height | 0.453" (11.50mm) |
| Current - UL | 12 A |
| Voltage - UL | 300 V |
