56 Connector Plug, Male Blades Board Edge, Through Hole, Right Angle Black VITA 46, Left End
2332816-1
| Category | Connectors, Interconnects - Backplane Connectors - Specialized |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | MULTIGIG RT 3 |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Connector Usage | Daughtercard |
| Connector Type | Plug, Male Blades |
| Connector Style | VITA 46, Left End |
| Number of Positions | 56 |
| Number of Positions Loaded | 53 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 7 |
| Number of Columns | 8 |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Termination | Press-Fit |
| Contact Layout, Typical | 4 Signal Pairs, 16 Single Signal, 6 Power Groups, 11 Ground, 3 Open |
| Features | Board Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Color | Black |
| Current Rating (Amps) | 75A |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -40°C ~ 125°C |
| Voltage Rating | 100V |
| Base Product Number | 2332816 |
| Product Attribute |  |
 |
 |
 |
| Part Number | 2332817-1 | 2334530-4 | 2334531-2 | 2334570-4 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| RoHS Status | RoHS non-compliant | Not applicable | ROHS3 Compliant | Not applicable |
| Description | VERT RCPT LEFT END HALF MULTIGIG | MBPLUS,R/A,PLUG,SOLDER,5LP + 24S | MBPLUS R/A HDR 20S + 6P | MBPLUS,R/A,REC.,SOLDER,5LP + 24S |
| Series | MULTIGIG RT 3 | MULTI-BEAM PLUS | MULTI-BEAM PLUS | MULTI-BEAM PLUS |
| Packaging | Tube | Tray | Tray | Tray |
