2425-018-X5U0-102MLF
lmages are for reference only.2425-018-X5U0-102MLF
CAP FEEDTHRU 1000PF 100V AXIAL
DatasheetAxial, Bushing, 1 Turret Lead
57,793 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1000 pF Feed Through Capacitor 100V 20 A Axial, Bushing, 1 Turret Lead
2425-018-X5U0-102MLF
| Category | Filters - Feed Through Capacitors - |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Series | 2425 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Tolerance | ±20% |
| Voltage - Rated | 100V |
| Current | 20 A |
| DC Resistance (DCR) (Max) | - |
| Operating Temperature | -55°C ~ 85°C |
| Insertion Loss | 20dB @ 100MHz |
| Temperature Coefficient | X5U |
| Ratings | - |
| Package / Case | Axial, Bushing, 1 Turret Lead |
| Size / Dimension | 0.187" Dia x 0.359" L (4.75mm x 9.12mm) |
| Height (Max) | - |
| Thread Size | 8-32 |
| Capacitance | 1000 pF |
| Mounting Type | Chassis Mount |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | 2425-018-X5U0-102M | 2425-018-X5U0-102P | 2425-018-X5U0-102PLF | 2425-018-X5W0-502M |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components | Tusonix a Subsidiary of CTS Electronic Components |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | CAP FEEDTHRU 1000PF 100V AXIAL | CAP FEEDTHRU 1000PF 200V AXIAL | CAP FEEDTHRU 1000PF 200V AXIAL | CAP FEEDTHRU 5000PF 100V AXIAL |
| Series | 2425 | 2425 | 2425 | 2425 |
| Packaging | Bulk | Bulk | Bulk | Bulk |
