2SB1647
lmages are for reference only.2SB1647
TRANS PNP DARL 150V 15A TO-3P
DatasheetTO-3P-3, SC-65-3
63,723 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor PNP - Darlington 150 V 15 A 45MHz 130 W Through Hole TO-3P
2SB1647
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Sanken Electric USA Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | PNP - Darlington |
| Current - Collector (Ic) (Max) | 15 A |
| Voltage - Collector Emitter Breakdown (Max) | 150 V |
| Vce Saturation (Max) @ Ib, Ic | 2.5V @ 10mA, 10A |
| Current - Collector Cutoff (Max) | 100µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 5000 @ 10A, 4V |
| Power - Max | 130 W |
| Frequency - Transition | 45MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-3P-3, SC-65-3 |
| Supplier Device Package | TO-3P |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 2SB1648 | 2SB1649 | 2SB1001BJTR-E | 2SB1002CJ90TL |
| Manufacturer | Sanken Electric USA Inc. | Sanken Electric USA Inc. | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | Not applicable |
| Description | TRANS PNP DARL 150V 17A MT-200 | TRANS PNP DARL 150V 15A TO-3PF | TRANS PNP 16V 2A UPAK | SMALL SIGNAL BIPOLAR TRANS PNP |
| Series | - | - | - | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
