Product CatalogPart Number
2SB1648
Manufacturer
Sanken Electric USA Inc.Description
TRANS PNP DARL 150V 17A MT-200
Datasheet
DatasheetPackage
3-ESIP
In Stock
70,864 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
2SB1648
2SB1648
lmages are for reference only.Payment Methods
Delivery Services
Bipolar (BJT) Transistor PNP - Darlington 150 V 17 A 45MHz 200 W Through Hole MT-200
Quick Inquiry
2SB1648
Specifications
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Sanken Electric USA Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Transistor Type | PNP - Darlington |
| Current - Collector (Ic) (Max) | 17 A |
| Voltage - Collector Emitter Breakdown (Max) | 150 V |
| Vce Saturation (Max) @ Ib, Ic | 2.5V @ 1.2A, 6A |
| Current - Collector Cutoff (Max) | 100µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 5000 @ 10A, 4V |
| Power - Max | 200 W |
| Frequency - Transition | 45MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 3-ESIP |
| Supplier Device Package | MT-200 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | 2SB1647 | 2SB1649 | 2SB1001BJTR-E | 2SB1002CJ90TL |
| Manufacturer | Sanken Electric USA Inc. | Sanken Electric USA Inc. | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | Not applicable |
| Description | TRANS PNP DARL 150V 15A TO-3P | TRANS PNP DARL 150V 15A TO-3PF | TRANS PNP 16V 2A UPAK | SMALL SIGNAL BIPOLAR TRANS PNP |
| Series | - | - | - | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
