54LS20DMQB
lmages are for reference only.54LS20DMQB
IC GATE NAND 2CH 4-INP 14CERDIP
Datasheet14-CDIP (0.300", 7.62mm)
30,538 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NAND Gate IC 2 Channel 14-CERDIP
54LS20DMQB
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | National Semiconductor |
| Series | 54LS |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Base Product Number | 54LS20 |
| Logic Type | NAND Gate |
| Number of Circuits | 2 |
| Number of Inputs | 4 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 2.2 mA |
| Current - Output High, Low | 400μA, 4mA |
| Input Logic Level - Low | 0.7V |
| Input Logic Level - High | 2V |
| Max Propagation Delay @ V, Max CL | 15ns @ 5V, 50pF |
| Operating Temperature | -55＜C ~ 125＜C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CERDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 54LS03/BCA | 54LS08LMQB | 54LS13/BCA | 54LS136DMQB |
| Manufacturer | Rochester Electronics, LLC | National Semiconductor | Rochester Electronics, LLC | National Semiconductor |
| RoHS Status | Not applicable | Not applicable | Not applicable | Not applicable |
| Description | IC DUAL | IC GATE AND 4CH 2-INP 20LCCC | IC DUAL | IC GATE XOR 4CH 2-INP 14CERDIP |
| Series | * | 54LS | * | 54LS |
| Packaging | Bulk | Bulk | Bulk | Bulk |
