ACM4520V-421-2P-T00
lmages are for reference only.ACM4520V-421-2P-T00
CMC 1.4A 2LN 420OHM SMD AEC-Q200
DatasheetHorizontal, 4 PC Pad
25,353 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2 Line Common Mode Choke Surface Mount 420 Ohms @ 100 MHz 1.4A DCR 55mOhm
ACM4520V-421-2P-T00
| Category | Filters - Common Mode Chokes - |
| Manufacturer | TDK Corporation |
| Series | ACM-V |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | - |
| Current Rating (Max) | 1.4A |
| DC Resistance (DCR) (Max) | 55mOhm |
| Voltage Rating - DC | 50V |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Approval Agency | - |
| Features | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 0.185" L x 0.177" W (4.70mm x 4.50mm) |
| Height (Max) | 0.079" (2.00mm) |
| Package / Case | Horizontal, 4 PC Pad |
| Base Product Number | - |
| Impedance @ Frequency | 420 Ohms @ 100 MHz |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ACM4520V-421-2P-TL00 | ACM4520V-142-2P-T00 | ACM4520V-142-2P-TL00 | ACM4520V-231-2P-T00 |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 1.4A 2LN 420OHM SMD AEC-Q200 | CMC 1A 2LN 1.4K OHM SMD AEC-Q200 | CMC 1A 2LN 1.4K OHM SMD AEC-Q200 | CMC 1.5A 2LN 230OHM SMD AEC-Q200 |
| Series | ACM-V | ACM-V | ACM-V | ACM-V |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
