ACS710KLATR-12CB-T
lmages are for reference only.ACS710KLATR-12CB-T
SENSOR CURRENT HALL 12.5A AC/DC
Datasheet16-SOIC (0.295", 7.50mm Width)
86,642 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Current Sensor 12.5A 1 Channel Hall Effect, Open Loop Bidirectional 16-SOIC (0.295", 7.50mm Width)
ACS710KLATR-12CB-T
| Category | Sensors, Transducers - Current Sensors - |
| Manufacturer | Allegro MicroSystems |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| For Measuring | AC/DC |
| Sensor Type | Hall Effect, Open Loop |
| Current - Sensing | 12.5A |
| Number of Channels | 1 |
| Output | Ratiometric, Voltage |
| Sensitivity | 56mV/A |
| Frequency | DC ~ 120kHz |
| Linearity | ±0.25% |
| Accuracy | ±2.2% |
| Voltage - Supply | 3V ~ 5.5V |
| Response Time | 4µs |
| Current - Supply (Max) | 14.5mA |
| Operating Temperature | -40°C ~ 125°C |
| Polarization | Bidirectional |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | ACS710 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ACS710KLATR-12CB-NL-T | ACS710KLATR-10BB-NL-T | ACS710KLATR-10BB-T | ACS710KLATR-25CB-NL-T |
| Manufacturer | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SENSOR CURRENT HALL 12.5A AC/DC | SENSOR CURRENT 10A | SENSOR CURRENT 10A | SENSOR CURRENT HALL 25A AC/DC |
| Series | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
