ACS759LCB-100B-PFF-T
lmages are for reference only.ACS759LCB-100B-PFF-T
SENSOR CURRENT HALL 100A AC/DC
Datasheet5-CB Formed Leads, PFF
10,341 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Current Sensor 100A 1 Channel Hall Effect, Open Loop Bidirectional 5-CB Formed Leads, PFF
ACS759LCB-100B-PFF-T
| Category | Sensors, Transducers - Current Sensors - |
| Manufacturer | Allegro MicroSystems |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| For Measuring | AC/DC |
| Sensor Type | Hall Effect, Open Loop |
| Current - Sensing | 100A |
| Number of Channels | 1 |
| Output | Ratiometric, Voltage |
| Sensitivity | 13.2mV/A |
| Frequency | DC ~ 120kHz |
| Linearity | ±1% |
| Accuracy | ±4% |
| Voltage - Supply | 3V ~ 3.6V |
| Response Time | 4µs |
| Current - Supply (Max) | 13.5mA |
| Operating Temperature | -40°C ~ 150°C |
| Polarization | Bidirectional |
| Mounting Type | Through Hole |
| Package / Case | 5-CB Formed Leads, PFF |
| Supplier Device Package | 5-CB Module |
| Base Product Number | ACS759 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ACS759LCB-050B-PFF-T | ACS750ECA-100 | ACS750LCA-050 | ACS750LCA-075 |
| Manufacturer | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | SENSOR CURRENT HALL 50A AC/DC | SENSOR CURRENT HALL 100A AC/DC | SENSOR CURRENT HALL 50A AC/DC | SENSOR CURRENT HALL 75A AC/DC |
| Series | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems | Allegro MicroSystems |
| Packaging | Tube | Tube | Tube | Tube |
