ADM7151ACPZ-02-R2
lmages are for reference only.ADM7151ACPZ-02-R2
800MA ULN 1.5TO4VO ADJ LDO
Datasheet8-WFDFN Exposed Pad, CSP
33,038 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 800mA 8-LFCSP-WD (3x3)
ADM7151ACPZ-02-R2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 16V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | 4V |
| Voltage Dropout (Max) | 1.2V @ 800mA |
| Current - Output | 800mA |
| Current - Quiescent (Iq) | 7 mA |
| PSRR | 94dB ~ 50dB (1kHz ~ 1MHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad, CSP |
| Supplier Device Package | 8-LFCSP-WD (3x3) |
| Base Product Number | ADM7151 |
| Current - Supply (Max) | 12 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADM7151ACPZ-02-R7 | ADM7151ACPZ-04-R7 | ADM7151ARDZ-02 | ADM7151ARDZ-02-R7 |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LIN POS ADJ 800MA 8LFCSP | IC REG LIN POS ADJ 800MA 8LFCSP | IC REG LIN POS ADJ 800MA 8SOIC | IC REG LIN POS ADJ 800MA 8SOIC |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
