AK3101
lmages are for reference only.AK3101
IC CORELESS CURRENT SENSE 14SOP
Datasheet24-PowerLSSOP (0.220", 5.60mm Width), 14 Leads
62,512 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Current Sensor 10.7A 1 Channel Hall Effect, Open Loop Unidirectional 24-PowerLSSOP (0.220", 5.60mm Width), 14 Leads
AK3101
| Category | Sensors, Transducers - Current Sensors - |
| Manufacturer | Asahi Kasei Microdevices/AKM |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| For Measuring | AC/DC |
| Sensor Type | Hall Effect, Open Loop |
| Current - Sensing | 10.7A |
| Number of Channels | 1 |
| Output | Ratiometric, Voltage |
| Sensitivity | 195mV/A |
| Frequency | 210kHz |
| Linearity | ±0.6% |
| Accuracy | ±1.5% |
| Voltage - Supply | 4.5V ~ 5.5V |
| Response Time | 2µs |
| Current - Supply (Max) | 20mA |
| Operating Temperature | -40°C ~ 90°C |
| Polarization | Unidirectional |
| Mounting Type | Surface Mount |
| Package / Case | 24-PowerLSSOP (0.220", 5.60mm Width), 14 Leads |
| Supplier Device Package | 24-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AK3102 | AK3103 | AK310H | CSNF151-001 |
| Manufacturer | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Honeywell Sensing and Productivity Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | IC CORELESS CURRENT SENSE 14SOP | IC CORELESS CURRENT SENSE 14SOP | IC CORELESS CURRENT SENSE 14SOP | SENSOR CURRENT HALL 180A AC/DC |
| Series | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Asahi Kasei Microdevices/AKM | Honeywell Sensing and Productivity Solutions |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Bulk |
