AL5802LP-7
lmages are for reference only.AL5802LP-7
IC LED DRVR LIN PWM 150MA 6DFN
Datasheet6-UFDFN Exposed Pad
93,684 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output Linear PWM Dimming 150mA U-DFN1616-6 (Type F)
AL5802LP-7
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Linear |
| Topology | - |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 4.5V |
| Voltage - Supply (Max) | 30V |
| Voltage - Output | 30V |
| Current - Output / Channel | 150mA |
| Frequency | - |
| Dimming | PWM |
| Applications | Signage |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN Exposed Pad |
| Supplier Device Package | U-DFN1616-6 (Type F) |
| Base Product Number | AL5802 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AL5802LP4-7 | AL5802LPL-7 | AL5801W6-7 | AL5801W6Q-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRVR LIN PWM 100MA 6DFN | IC LED DRVR LIN PWM 120MA 6DFN | IC LED DRVR LIN PWM 350MA SOT26 | IC LED DRVR LIN PWM 350MA SOT26 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
