AMS22U5A1BLARL301
lmages are for reference only.AMS22U5A1BLARL301
SENSOR ROTARY 10DEG SOLDER LUG
DatasheetModule, Round Shaft
12,118 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Hall Effect Sensor Rotary Position Round Shaft Solder Lug
AMS22U5A1BLARL301
| Category | Sensors, Transducers - Position Sensors - Angle-Linear Position Measuring |
| Manufacturer | Bourns Inc. |
| Series | AMS22U |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| For Measuring | Rotary Position |
| Technology | Hall Effect |
| Rotation Angle - Electrical, Mechanical | 10°, Continuous |
| Linear Range | - |
| Output | Analog Voltage |
| Output Signal | Clockwise Increase |
| Actuator Type | Round Shaft |
| Linearity | ±0.5% |
| Resistance | - |
| Resistance Tolerance | - |
| Voltage - Supply | 5V |
| Mounting Type | Panel Mount |
| Termination Style | Solder Lug |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | Module, Round Shaft |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Base Product Number | AMS22U |
| Product Attribute |  |
 |
 |
 |
| Part Number | AMS22U5A1BLARL302 | AMS22U5A1BLARL303 | AMS22U5A1BLARL304 | AMS22U5A1BLARL305 |
| Manufacturer | Bourns Inc. | Bourns Inc. | Bourns Inc. | Bourns Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SENSOR ROTARY 20DEG SOLDER LUG | SENSOR ROTARY 30DEG SOLDER LUG | SENSOR ROTARY 40DEG SOLDER LUG | SENSOR ROTARY 50DEG SOLDER LUG |
| Series | AMS22U | AMS22U | AMS22U | AMS22U |
| Packaging | Bulk | Bulk | Bulk | Bulk |
